[Chivalry] Mason Knight - The Face of Revolution, Maul of Sanguine Retribution

13

Replies

  • zetheros
    Offline / Send Message
    zetheros sublime tool
    eh, I could, but there's only about 10 days left in the competition, and 2048x2048 is already more than enough resolution for a throwing axe. In fact I might even have to scale down the res just so it looks like it belongs in the game.
  • zetheros
    Offline / Send Message
    zetheros sublime tool
    Sort of fell asleep around 1:30ish, but I'm cutting out the UV for the mace :) The power is out and the internet is down, laptop is tethered to my phone. Hopefully the power goes back online.
  • zetheros
    Offline / Send Message
    zetheros sublime tool
    @jo420; I don't think throwing weapons have blood masks, since they disappear when they hit a target. I'll post a screenshot of the axe without the blood to see which one looks better.
  • JO420
    Offline / Send Message
    JO420 polycounter lvl 18
    Have you thought they might not even include throwing weapons,the rules say only main weapons will be considered. Thats why my scimitar went from a 1 hand archer weapon to a 2 handed messer.
  • zetheros
    Offline / Send Message
    zetheros sublime tool
    Throwing weapons are secondary weapons, sort of like shields. It doesn't get factored into the judging, but I want to make sets that people would want to buy, not a set that's sole purpose is to win this competition. If you had two sets that were identical in awesomeness and pricing, but one set had an additional model replacement for the throwing axe, which one would you get? The more stuff that's in a pack, the merrier!
  • JO420
    Offline / Send Message
    JO420 polycounter lvl 18
    zetheros wrote: »
    Throwing weapons are secondary weapons, sort of like shields. It doesn't get factored into the judging, but I want to make sets that people would want to buy, not a set that's sole purpose is to win this competition. If you had two sets that were identical in awesomeness and pricing, but one set had an additional model replacement for the throwing axe, which one would you get? The more stuff that's in a pack, the merrier!

    Yo yo wasn't meant to be discouraging, was an FYI. Hate for you to put in a lot of work for nothing.
  • zetheros
    Offline / Send Message
    zetheros sublime tool
    @JO420; haha, no worries, I didn't take it as discouragement. And I really love this kind of work (the other main reason why I make extra set pieces). If I don't win, I wouldn't really care, since it's a lot of fun, I learned a lot, and I'll have some great pieces for my portfolio.

    Anyway, oops! Internet was down for two days, power was out for another day, and I ran out of money on my phone so I couldn't call anyone. Talk about fun :D

    Managed to get some work though. Here are all the screens that I would have posted, but couldn't. There's still a lot of tinkering to do, though.

  • zetheros
    Offline / Send Message
    zetheros sublime tool
    Currently still adding a lot of base painting, highlights and shadows, fixing small areas of normal and diffuse map, etc. Will probably be done by morning, then I'll work on the helmet, or perhaps specular mapping and importing into chiv SDK.

    Mesh explosion helped a lot for the normal map. I sort of wanted to do it for the AO map too, but I ended up deciding that the shadows of the horns/feather appendages really puts the weapon together, aesthetically.
  • Nolt
    Offline / Send Message
    Nolt polycounter lvl 13
    Man that's looking nice! Looking forward to seeing it finished!
  • zetheros
    Offline / Send Message
    zetheros sublime tool
    Thanks! Taking a quick snack break atm, but I'm having a lot of fun with this mace project, and I'm sure it'll be done soon. One thing I learned is that my high-poly repousse detail is a bit too fine for the normal map to pick up, so I selected the polygons of the surface repousse and moved them out a bit, then rebaked.

    It's a quick fix because the deadline is closing, but I'll know in the future to make more pronounced details for normal map baking.
  • Nolt
    Offline / Send Message
    Nolt polycounter lvl 13
    That's where isn't important to prioritize your UV space on what has tons of details, what's larger, etc. What size are you baking your maps at? I normally bake 1 size up from the final size I am aiming for.
  • zetheros
    Offline / Send Message
    zetheros sublime tool
    Hey 9th, I'm baking them at 1:1, haha. What is 1 size up? Like 1024 to 2048? Does that make for a more accurate bake?

    I've baked maps for this weapon at the guideline sizes; normal and diffuse at 2048.

    I generally keep UV shells in proportion to each other, but the areas near the hilt, handle, etc would get a little more attention.
  • Nolt
    Offline / Send Message
    Nolt polycounter lvl 13
    zetheros wrote: »
    Hey 9th, I'm baking them at 1:1, haha. What is 1 size up? Like 1024 to 2048? Does that make for a more accurate bake?

    I've baked maps for this weapon at the guideline sizes; normal and diffuse at 2048.

    I generally keep UV shells in proportion to each other, but the areas near the hilt, handle, etc would get a little more attention.

    Yeah, like if I am aiming for a 1024, I bake it at 2048 just because you get crisper details initially and they are more likely to hold up when downsizing depending on how much smaller that actually makes the parts.

    It's good that they're pretty relative to one another. Texture space can just be used a bit more efficiently if you have a blank part with little detail and making it smaller to allow more space for more detailed areas.
  • alexd
    Good job mate! But i recall you had some awesome shield ? What happened with it ?
  • zetheros
    Offline / Send Message
    zetheros sublime tool
    Heearrrgghh matie!

    I'll get to that other set soon. I'm redoing the mace's normal, AO, and diffuse maps, I ended up having to do so much manual tinkering and fixing of the maps, that I decided it was better to just start over from scratch. :D
  • Imperium101
    I am learning that too: truly a challenge. But this aside:

    all your sets look great zetheros, pls do not neglect the two other ones !

    I would really like to play with them in Chiv.

    Good luck,

    TheMightyKnight

    http://www.polycount.com/forum/showthread.php?t=140143
  • alexd
    Even if you dont have time to finish all, finish and submit it after the contest as a regular steam submission :)
  • Imperium101
    We might still get them ! We will vote for them !


    TheMightyKnight

    http://www.polycount.com/forum/showthread.php?t=140143
  • zetheros
    Offline / Send Message
    zetheros sublime tool
    Got the maul into the SDK. It's very easy, as long as you read the instructions slowly and carefully.

    I'm very confident I can finish my three submission in 5 days, now that I know the complete steps from concept to 3d to importing into an SDK. I have a feeling that submitting the item to the workshop won't take very long :D

    My brother said the maul's metal texture was going to be too light, once it's in the SDK, and even lighter still with an specular map that I haven't added yet, so I'm going to add a specular map next, tone down the brightness, and add final adjustments before finishing the rest of this set, and moving onto The Crown of Cobalt, and the Blade of Mercurial Wrath.

  • jackalope
    Offline / Send Message
    jackalope polycounter lvl 11
    Looking good. In general a metal texture's diffuse should be pretty dark, and the specular is very light. It differs based on what metal you want but chrome would basically be black diffuse and white specular (not speaking to gloss or whatnot).
  • zetheros
    Offline / Send Message
    zetheros sublime tool
    Oh, the specular is supposed to be light too? I thought they were supposed to be both dark, at least on metal parts. IIRC black designates shiny parts of the specular map, and white designates not shiny textures.

    This is what it looks like when I made the diffuse too dark, and also the specular a little too dark (shiny).

  • Dylan Brady
    Offline / Send Message
    Dylan Brady polycounter lvl 9
    zetheros wrote: »
    Oh, the specular is supposed to be light too? I thought they were supposed to be both dark, at least on metal parts. IIRC black designates shiny parts of the specular map, and white designates not shiny textures.
    You might be confusing spec with roughness. but either way, White is most shiny, black is least shiny.
    and actually the diffuse should be darker, and the spec lighter. not both lighter.
  • zetheros
    Offline / Send Message
    zetheros sublime tool
    Ohhh, thanks! I was also sort of confused by the polish level on my maul, which made me think that my specular was working...

    After changing my specular map a few times, I noticed nothing was really happening. I found out that the material from the tutorial at https://tornbannerjira.atlassian.net/wiki/display/CHIVCOM/Tutorial%3A+Adding+New+Weapon+Skins+to+Chivalry

    uses "M_Weapons_Master". It's a bit too shiny, and sort of obscures the normal map and really shows the low-poly geo, which is what I don't want. I'm going to see how to change the material settings, and also change my specular to a lighter color.
  • zetheros
    Offline / Send Message
    zetheros sublime tool
    This is what it looks like with just the material on the skeleton mesh, and no maps.

  • zetheros
    Offline / Send Message
    zetheros sublime tool
    Oh wow, I just saw there's "apex clothing asset" in the sdk too. Would be interesting to use for cloth materials on weapons.
  • zetheros
    Offline / Send Message
    zetheros sublime tool
    Okay, I figured out how to change the shininess on the material, it's in the next step with environmental map mask intensity, specular map intensity, and specular power.
  • alexd
    Nice progress mate!
  • alexd
    Btw where are the steps you followed for the udk ? In the main Announce page ?
  • zetheros
    Offline / Send Message
    zetheros sublime tool
    Aye, follow this tutorial: https://tornbannerjira.atlassian.net/wiki/display/CHIVCOM/Tutorial%3A+Adding+New+Weapon+Skins+to+Chivalry

    Make sure to read it carefully though... everything talked about is important and necessary, and it can be a little difficult to digest if you're completely new to UDK or this chiv SDK.

    The basic gist is that you need all of your maps and your model saved in two FBX files; one with two bones, one without the bones. That's for weapons, I'm sure the process is similar with helmets, but I haven't tried yet.

    If you have any questions, feel free to PM me!
  • alexd
    Thank you very much :)
  • zetheros
    Offline / Send Message
    zetheros sublime tool
    Well since I already know what to do (clean up and enhance my TGAs, fix the wonky looking beak, play with specular settings, make a blood mask, append the weapon to the mason knight), I'm going to set this project aside and get the more difficult parts out of the way first. I'm going to get the hi-poly stechhelm done, then bake normals, the rough diffuse, AO, specular, and basically get it to where the maul is now. Same with the francisca axe, should be done before afternoon.

    If you feel like something is off, like the specular or diffuse looks too dark, it might be because part or all of your normal map somehow became inverted when importing to the SDK.

    You can go into photoshop, select the area that appears to be inverted, and do Image > Adjustments > Invert (Ctrl - I) and save your TGA. Reload the image in Chiv SDK, then undo the invert you just did in photoshop, save, and reload the image again. It worked for this mesh. :)

  • zetheros
  • pior
    Offline / Send Message
    pior grand marshal polycounter
    I am not exactly sure to understand what you mean by this piece of advice : "select the area that appears to be inverted".

    It's actually a "all or nothing" situation : a normalmap has either its y/green channel inverted compared to what an engine expects, or not. If some areas seem more broken than others, that means that there is another issue at play.

    (now of course I am glad that you managed to get something that looks fine - I am just trying to make sure that technical misinformation is not spreading too much, as it has been the case in the past :) )

    Similarly, if everything is setup properly there should be no need to "clean up" a bake, at all. Now of course if time is running short and/or the tool being used to generate the normalmap is not properly synced with the engine, it might seem to be necessary. But there is always a way to make things technically correct to begin with. I can actually happily report that the Unreal option of Handplane works flawlessly, hence I would suggest using that (if time allows of course !)
  • zetheros
    Offline / Send Message
    zetheros sublime tool
    Ahh, well this maul is actually my first foray into baking maps, I definitely messed up here and there, but it'll look better after I work on the diffuse. Learning the workflow for making game assets, and having a good end result is a good enough goal for me.

    Sorry if I accidentally spread misinformation, but the technique did work for me. Perhaps my normal map did not invert, it could have been a myriad of different possibilities.

    I have to smooth out some sections of my normal map, the problem was with my high-poly model; some of the creases and edges were laying too close to the surface of the rest of the mesh to pick up with my low-poly + normal map.

    I'll look into using handplane, thanks Pior!
  • pior
    Offline / Send Message
    pior grand marshal polycounter
    No worries man - and don't hesitate to ask if you run into any bump in the road.

    This whole baking process has been basically turned into something much more convoluted that it should be because of the lack industry wide standards (for instance, some programs used to generate normalmaps cannot display their own maps properly), but thankfully, the people behind Handplane managed to almost completely solve the issue thanks to their original approach.

    On a side note, and quite ironically, the *only* engine that I know of providing a completely synchronized workflow from the baking tool to the final display is IDTech, going back to the Doom3 days. The baking tool is integrated inside the game engine, for flawless map generation. It's gorgeous :)

    But now that Handplane provides compatibility options with Source and UDK, things are easier now! Until recently, working with these engines was still very approximative.
  • zetheros
    Offline / Send Message
    zetheros sublime tool
    Thanks Pior! That's awesome. I remember when doom 3 came out... I think I was like 11 or 12, or something. I got to the point where a guy was trapped under a door, screaming for help. When I walked near, he was dragged under the door to the other room by some horrible spawn of evil. Then I stopped playing....

    Adding the finishing touches to the repousse of the helmet. It's a bunch of scary masons pushing Simba's dad off a cliff :'(

  • Noth
    Offline / Send Message
    Noth polycounter lvl 15
    lmao, That's pretty funny imagery to include there man.
  • zetheros
    Offline / Send Message
    zetheros sublime tool
    haha xD

    And that's how I make repousse for the normal map bake. It's really fast and easy, and feel free to use the method if you can't think of anything else. I made a few zsphere figurines, turned them into adaptive skins, flattened them with the move tool, and added a bit of noise with just clay build up.

    It should bake fairly well, I made sure to leave the details far more prominent this time. The rest of the details can be hand painted.

    I can't really think of anything else to improve for this helmet (well, I can, but improvements can always be made, and you have to know when to stop)

    Onto the low poly!

  • zetheros
    Offline / Send Message
    zetheros sublime tool
    Decimated, transposed into one subtool, beginning retopo!

  • zetheros
    Offline / Send Message
    zetheros sublime tool
    Done with the retopo...time for sleep.

    It's 1200 tris, yep the inside has geo too.

  • dudeface
    Did jousting helmets really have such strange things on top?
  • zetheros
    Offline / Send Message
    zetheros sublime tool
    Ah, this question comes up often. It's certain that they did;



    There are also many coats of arms and house symbols that include the stechhelm with ornate plumes, often featuring something bird-related. I'm pretty sure some of these are not from the times, but several are.

    url?sa=i&source=images&cd=&docid=T4xGZWgeF1F3pM&tbnid=55ahqX0ewvP40M:&ved=0CAUQjBw4JQ&url=http%3A%2F%2Fwww.zeno.org%2FKunstwerke.images%2FI%2F323D031a.jpg&ei=6WAqVKzyNOTiywPgnoDwDA&psig=AFQjCNHji1Xny8UrHN5qtE260yB1EmzqFg&ust=1412149866008039
    cache_2437478809.jpg?t=1375999256
  • zetheros
    Offline / Send Message
    zetheros sublime tool
    And if you think that's strange, check out this guy;

  • Zelfit
    Offline / Send Message
    Zelfit polycounter lvl 8
    And if you think that's strange, check out this guy;
    Something like this is already in game, but with red and black colors, as I remember
  • zetheros
    Offline / Send Message
    zetheros sublime tool
    This is going to be fun.

  • Zelfit
    Offline / Send Message
    Zelfit polycounter lvl 8
    When you have small repeating things like this, just delete most of them, leave 3-4 variations. It will be easier to do uv and baking. After that you can duplicate them back
  • zetheros
    Offline / Send Message
    zetheros sublime tool
    I deleted half, it made making the UV easier.

    Done with the normal/diffuse. Going to rough out the colors, smooth parts of the AO map, and work with the normal map a bit before going into specular.
  • zetheros
    Offline / Send Message
    zetheros sublime tool
    Here's the preview. Instead of working on 3 sets, I think I'll just spend the rest of my time improving this set to... unholy levels of awesomeness. *sunglasses*

    http://grooveshark.com/s/Metal+Invasion/1Yyglg?src=5

  • Zelfit
    Offline / Send Message
    Zelfit polycounter lvl 8
    Shading on the top part of helmet looks too dark, maybe some normal map issues
  • Syros
    Offline / Send Message
    Syros polycounter lvl 11
    trembling inside man, what a nice thread afetr all , keep it up \m/
