Tomb Raider Anniversary Edition - handful of chars
polycounter lvl 18
Sup polycounters - here is some of the character work I did for Tomb Raider Anniversary Edition. You may recognize some of the likenesses from the very first version of the game (1994)
The character concepts were done by Crystal Dynamics/Eidos. The modeling and texturing were done by myself...
It was a fun project to work on, and I hope I get the opportunity to work with Crystal Dynamics again in the future...
The knife and pistols being held were done by Crystal Dynamics
Kold
Pierre
Larson
Qualopec
Kid
Thanks for looking...
The character concepts were done by Crystal Dynamics/Eidos. The modeling and texturing were done by myself...
It was a fun project to work on, and I hope I get the opportunity to work with Crystal Dynamics again in the future...
The knife and pistols being held were done by Crystal Dynamics
Kold
Pierre
Larson
Qualopec
Kid
Thanks for looking...
Replies
man i love the tomb raider series. anniversary was cool until i met those damn centaurs:)
Anyways great stuff man.
I fixed the link!
Kinda reminding me of the Sega brawler Spikeout.
Don't get me wrong, but I think your ears and shoulders on all the models need more loving. The silhouette is looking a little chunky.
Minor crit, it all looks great man.
i'm loving the kid very much. some cool detailing in the texture going on
any chance to show some wireframes to study the topology?
i like the tut too much ,
0- which application did you use ?
1- how many polys for each character please , approximately .
2- how much time did it take to make a character .
3- since when you are using 3d applications
btw, congrats with the game.
(edit) forgot to say: your tutorial on the head painting is great! i learned from you
Bryan - jesus.. long time no see. How ya been? Still at Nerve? Nice work on your new page...
Ruz - you're not the first I've heard complain about those suckers. Actually, when I was testing stuff in that phase of the game (errors with Pierre in that scene), it wouldn't take too long for me to die.. so I feel your pain
culturedbum - thanks -- they're all hand painted. As a mini-game for myself, I didn't use any assetts outside of what could be made in Photoshop (no image overlays, etc..), just to see what the results would be. I learned a lot, but I've switched back to using photo overlays now...
Hawken - Thanks.. I have a feeling you're looking at the posed Pierre (in reference to the shoulders). That was just some funky weighting that I didnt catch when I took the snapshot... I actually take great pride in my shoulders! :P
Mop - That char was a bitch to model and stay within limitations.. Ill keep an eye on the shoulder to bicep area in the future. Thanks for pointing that out
P3wp - You're such a home-owner . I'll keep those color observations in mind for the next round of stuff!
bitmap - The images shown are the ones that Eidos approved. Showing wires and/or flats could be definied as sharing trade secrets, so unfortunately I can't show them. Don't worry though, you're not really missing out on anything :P
Ged - Thanks man -- just wanted something that was clear and easy to read on screen
3DGuru - I modeled in Max, and textured in Photoshop. These characters ranged from 4,000 to 7,000 polys. It would generally take me a week to a week and a half for a character (I think Qualopec took 2 weeks). I've been using 3D apps for 7 years...
Daz - good call on the highlights. Glad yo udig the work -- I'm a huge fan of yoru water colors and character work in the James Bond title
Blazier - thanks man
xysdf - glad you dig the tut. These characters actually all have 2 hard light layers for that exact purpose.. one light green, and one light cyan. I didn't want to 'bake in' too much of an artificial shine though, as I don't think it would hold up too well to different lighting scenarios (also keep in mind that these characters are inside tombs 99% of the game)
Thanks guys
- BoBo
Cheers
Bobo - Thanks
Aes - I can't show any of the UVs for these characters. That could be deemed as 'trade secrets,' and Eidos has already signed off on these images alone.
I have UV examples on my site from other titles, and old stuff.. if those are of any use to you.
Tips on UV Mapping from this round of chars:
Keep straight lines on objects that have straight lines. It's a great way to fake in more detail via pixel painting. IE- a 1 pixel line that runs straight horizontal or vertical (or exactly 45 degrees) looks much sharper than a 1 pixel line at an odd angle. Look at Kid's hat - the amount of UV space that hat takes up is extremely small. I got sharp detail across by limiting the 1 pixel lines to horz and vert, and even used a slight UV nudge to introduce a really fine black line that seperates the front of the hat from the back... get creative with UVs! ( Kenneth Scott influence )
Also, get creative with your mirroring and tiling. Again looking at Kid, check out his bandana... look how sharp I got the design. It's only one and a half rows of the skull design on the tex sheet.. I just tile it across the whole bandana, with two equa-distant shadows (fro mhat and bandana bottom) across the whole tile.
Larsons plaid shirt.. all straight horz and vertical pixel painted lines... Pierres turtle neck - same thing as Kid's bandana.. just a small pixel painted texture. Takes up virtually no texture space, but puts in tons of detail. The belt loops are a tiling texture across the board as well.. :P
Renaud - Thanks man.. for some reason he's my least favorite one. I like Kold the best if I had to choose one - althoug h I'm kind of sick of looking at them. These chars are over a year old to me by now...
Johny - thanks man - yeah I agree with him too. I'm always trying to keep a steep saturation level i my textures for some reason.. Ill keep an eye on that
[email="Por@szek"]Por@szek[/email] - thanks man - I dig your work as well. Have seen you around quite a bit :P
nkoste - thanks man - I try not to get too carried away with fake speculars (really sharp ones) on my textures. In this case, these characters were underground in dark tombs for most of the game, so that's one conscious reason I chose not to go that route. I'm glad you find the tut useful! I should write another one.. that one's almost 2 years old now...
Looks real nice buddy. I love the details you got in the face. I have the same crit for these guys as I always give you, and that's skin tone. They all have a very orange hue to them, which works ok in the face, but on the body looks like a very sunburnt or native american look. I'd love to see you try to tackle a paler skin tone or one based on pink instead of orange.
Minor crit, it all looks great man.
[/ QUOTE ]
You took all the words right out of my mouth. It was nice seeing your stuff Jon. Always top notch.
ben
It all looks very good. Is it possible to see closeups of the faces untextured please? Thanks
