Virtual terrain textures rathern than meshes?

NAIMA

Hello , what does it means in this video ...

https://youtu.be/xKWa4WoTkV4?si=VN3DlsGFhklLXHaz&t=1766

Virtual terrain textures rather than meshes?
What is batch rendering?
What is machine learning super resolution technique?

gnoop

What time is it  in the video?

NAIMA

gnoop said:

What time is it  in the video?

What you mean ? I linked to the actual starting point .

Ok for some reasons seems it didn't work ... check from 29 minutes onward.

Eric Chadwick

You have to format the link without the mobile URL (youtu.be) so it looks more like this, but unfortunately Vanilla Forum software doesn't support timestamped embeds, FML. So you have to copy/paste the URL into a new tab or window.

https://www.youtube.com/watch?v=xKWa4WoTkV4&t=1766s

Eric Chadwick

There's not much info in the video there. But if you search star citizen virtual terrain texturing there are some interesting links, like https://www.adobe.com/products/substance3d/magazine/star-citizen-texturing-sci-fi-open-world-game-substance.html

poopipe

Virtual texturing generally refers to a mechanism that allows you to only stream in the the parts of a texture that you can see at the mip level that you can see.

Unreal has its own implementation but everyone else will be building it on top of directx12

It should be largely transparent to the artist and really just means you can throw a lot of texture data around in a more efficient way than with conventional dx11 type streaming

NAIMA

Yes , but what does it means, " instead then meshes" ? What are they referring to ?

poopipe

it looks like they send the terrain to the GPU as a texture and generate the mesh there instead of making a mesh and sending that to the GPU. This isn't exactly revolutionary  - in fact, it's generally what you should be doing.

you don't have to store lods, you can take advantage of your texture streaming system, you can have smooth lodding, you don't have to calculate when your lods arrive cos it's based on mipping  and GPUs are far better at handling textures than anything else.
There are some disadvantages - like it being more difficult to do occlusion culling - but the advantages far outweigh the disadvantages.
I'm about 99% certain this is how unreal handles landscapes - it certainly stores them as textures in memory at runtime

i think where star citizen is being clever is the scale it's working at - its very, very large

gnoop

poopipe said:

it looks like they send the terrain to the GPU as a texture and generate the mesh there instead of making a mesh and sending that to the GPU. This isn't exactly revolutionary  - in fact, it's generally what you should be doing.

you don't have to store lods, you can take advantage of your texture streaming system, you can have smooth lodding, you don't have to calculate when your lods arrive cos it's based on mipping  and GPUs are far better at handling textures than anything else.
There are some disadvantages - like it being more difficult to do occlusion culling - but the advantages far outweigh the disadvantages.
I'm about 99% certain this is how unreal handles landscapes - it certainly stores them as textures in memory at runtime

i think where star citizen is being clever is the scale it's working at - its very, very large

So it's like dx 11  tessellation and displacement . I always thought that  it's sort of more expensive than just  doing  the  mesh and lods. While indeed simpler to do.     Is it other way around now?    As of occlusion culling  it could done in patches , right ?  So  we would see un occluded patches  displaced.

NAIMA

I am actually not understanding the technique .

Eric Chadwick

That’s ok, it’s not important to artists. That link I shared is more relevant, most likely.

poopipe

gnoop said:

poopipe said:

it looks like they send the terrain to the GPU as a texture and generate the mesh there instead of making a mesh and sending that to the GPU. This isn't exactly revolutionary  - in fact, it's generally what you should be doing.

you don't have to store lods, you can take advantage of your texture streaming system, you can have smooth lodding, you don't have to calculate when your lods arrive cos it's based on mipping  and GPUs are far better at handling textures than anything else.
There are some disadvantages - like it being more difficult to do occlusion culling - but the advantages far outweigh the disadvantages.
I'm about 99% certain this is how unreal handles landscapes - it certainly stores them as textures in memory at runtime

i think where star citizen is being clever is the scale it's working at - its very, very large

So it's like dx 11  tessellation and displacement . I always thought that  it's sort of more expensive than just  doing  the  mesh and lods. While indeed simpler to do.     Is it other way around now?    As of occlusion culling  it could done in patches , right ?  So  we would see un occluded patches  displaced.

Hardware tessellation is modifiying a mesh - there's no need for that in this scenario. It'll be a simple, regular heightfield grid with conventional smooth lodding just like you see in most game engines. the new/clever part is in how they stream texture data.

They mention patches and its the obvious way to manage that sort of thing so I expect you're correct in terms of occlusion culling.

gnoop

poopipe said:
Hardware tessellation is modifiying a mesh - there's no need for that in this scenario. It'll be a simple, regular heightfield grid with conventional smooth lodding just like you see in most game engines. the new/clever part is in how they stream texture data.

 I am still  not sure I understand the reason.  if it's regular grid mesh patches  and they displace it by height  textures in real time  it's still a hell lot more vertexes then  properly re-meshed  around terrain features model  with  lods.      More data to load , more math to do in  real time?

poopipe

not really no

When you're stood on a 1km square tile at 1m resolution you're handling/rendering a million verts with a static lod
in the same scenario on a heightfield with smooth lodding you ditch  a shit load of those vertices

that's before you consider the other reasons
1: you have to get those meshes to the GPU every time they lod
2: you have to generate thousands (if not millions) to cover a planet
3: you have to generate (and store) the lods
4: you have to iterate on all this.

Storing it all as textures means you don't have to send shit to the GPU all the time (which is very slow) and that you get your lods for free

gnoop

Thanks  poopipe , it makes sense .        Stiil  the properly tessellated/decimated   mesh  around  terrain surface features may need much less vertexes than a regular grid.     Like several times less  but my guess it still  more traffic toward the GPU than  just textures .
